Pothole Repairing Machine
Product Details:
X
Product Description
POTHOLE REPAIRING MACHINE
MANUFACTURED UNDER COLLABORATION WITH INDUSTRY LEADER, M/S CRAFCO INC., USA.
The AMZ quickly and effortlessly repairs potholes, shoulders, utility cuts, alligatored areas, cracks and fissures. Less than 1 kg. of pressure positions the boom anywhere within a 100 square metre working area with a vertical range of 1525 mm. above to 610 mm. below pavement level.
GENERAL
The following specifications cover a truck mounted road maintenance machine. Uses air to clean cracks and surfaces, spray hot emulsion over area to provide tack coat, and fully coated asphaltic material to provide dense coating to bring repaired area up to grade.
CHASSIS
TATA Model 1613/42 or equivalent.
MANUFACTURED UNDER COLLABORATION WITH INDUSTRY LEADER, M/S CRAFCO INC., USA.
The AMZ quickly and effortlessly repairs potholes, shoulders, utility cuts, alligatored areas, cracks and fissures. Less than 1 kg. of pressure positions the boom anywhere within a 100 square metre working area with a vertical range of 1525 mm. above to 610 mm. below pavement level.
GENERAL
The following specifications cover a truck mounted road maintenance machine. Uses air to clean cracks and surfaces, spray hot emulsion over area to provide tack coat, and fully coated asphaltic material to provide dense coating to bring repaired area up to grade.
CHASSIS
TATA Model 1613/42 or equivalent.
| DIMENSIONS | ||
| Length | : | 8650 mm. |
| Width | : | 2400 mm. |
| Height | : | 2900 mm. |
| DISCHARGE NOZZLE AND COATING SYSTEM | ||
| General | : | Capable of 100% coating prior to discharge. |
| Nozzle | : | Machined aluminium with internal spray ring-tapered to accelerate material. |
| Coating System | : | Spray bath at nozzle internal spray ring. |
| TANK | ||
| Asphalt tank | : | 950 ltrs. |
| Insulation | : | Fully insulated with weather tight cover. |
| Openings | : | 200 mm. quick opening. |
| Heating | : | 6000 watt - 110 V/220 V. |
| Fuel tank | : | 75 ltrs. |
| Flush tank | : | 150 ltrs. |
| ENGINE | ||
| Horsepower | : | Minimum 63 HP. |
| Filter | : | Oil bath. |
| Battery | : | 12 V/19 Plates. |
| WORKING AREA | ||
| Total | : | 100 Square metre |
| TRI-FOLD ARTICULATED BOOM WITH COUNTER-WEIGHTED ARM | ||
| Radius | : | 6360 mm. fully articulated. |
| Vertical stroke | : | 1525 mm. above to 610 mm. below Pavement-self supporting feature. |
| Controls | : | Operating position 1830 mm. from material spray minimum. |
| Air | : | High volume lobe blower. |
| AGGREGATE DELIVERY SYSTEM | ||
| Type | : | Screw fed to rear mounted power flow positive displacement air lock. |
| Air lock | : | Rear mounted. |
| Hopper capacity | : | 4.5 cu.m. (option 6 cu. m.) |
| HYDRAULIC SYSTEM | ||
| Pump | : | Low noise vane. |
| Flow controls | : | Pressure compensating. |
| Hydraulic tank | : | 85 ltrs. with sight gauge. |
| Filters | : | Dual-suction and return filter. |
ASPHALT DELIVERY SYSTEM
Through pressurized asphalt tank by opening valve control located at operator station.
COLOUR
Highway safety yellow or orange.
CRACK FILLING ATTACHMENT
Crack filling wand with regulator built into handle for applying asphalt emulsion only. Includes rear mounting brackets and self retracting reel.
ELECTRICAL
Single phase industrial 220 V generator to power asphalt emulsion tank heating element and insulated asphalt emulsion line.
OPTIONAL
Trailor mounted in place of Truck mounted.
CLEAN
The AMZ delivers up to 15.5m3 of air per minute at 320 kmph. for thorough cleaning.
TACK
Opening a valve injects hot asphalt emulsion, fully atomized by an internal spray ring, to create a high pressure spray bath producing an economical, thin tack coat.
FILL & COMPACT
Simply flipping a switch activates the positive displacement stone feeding system. Stone enters the airstream and passes through the nozzle's internal high pressure spray bath, assuring complete coating at an economical 5% asphalt content = 17 tons per tank.
FINISHED REPAIR.
